FEA 101 - Ansys Mechanical Introduction Training

Beginner Level Training - 2 days (16 hours)

About Ansys Mechanical Introduction Training by CADIT

Introduction to finite element analysis with Ansys Mechanical, covering the complete end-to-end workflow for linear static structural analysis — setup, solving, and result interpretation — with an overview of modal, thermal, and multi-step analyses.

Perfect for Engineers and analysts new to structural FEA.

Learning Outcomes

By the end of this training, you will be able to:
1. Perform a complete static structural analysis in Ansys Mechanical
2. Identify key considerations for building effective analysis models
3. Use essential tools: view control, geometry import, materials, meshing, loads, supports, and results
4. Understand the basics of solution accuracy and model validation

Course Content

1. Introduction
   - Overview of Ansys Mechanical capabilities
   - Applications in structural simulation
   2. Ansys Mechanical Demo
   - Live walkthrough of interface and workflow
   3. Geometry Handling
   - Introduction to Ansys SpaceClaim
   - Geometry import and cleanup
   4. Preprocessing
   - Model setup and boundary conditions
   - Material assignment
   - Mesh generation and control
   - Connections and remote boundary conditions (RBC)
   5. Structural Analysis
   - Linear static analysis workflow
   - Modal, thermal, and multi-step analyses
   - Submodeling
   6. Postprocessing
   - Interpreting results
   - Stress, deformation, and thermal outputs
   7. Wrap-up
   - Discussion & Q&A Assessment & feedback

HRDCorp Claimable Ansys Mechanical course

Certificate of completion provided. If based in Malaysia, this course can be reimbursed with the HRDCorp Program through our certified trainers.
