EMHF 204 - Ansys HFSS 3D Layout & GDS Import Workflow Training

Advanced Level Training - 1 day (8 hours)

About Ansys HFSS 3D Layout & GDS Import Workflow Training by CADIT

Training in importing GDS files of interposer structures into IC mode of Ansys HFSS 3D Layout, using control files to manage import and correctly configuring models for electromagnetic simulation of high-speed IC and package designs.

Perfect for IC package and interposer design engineers.

Learning Outcomes

By the end of this training, you will be able to:
1. Step through a typical GDS import process.
2. Understand the basics of .map and .xml control files to assist the GDS import.
3. Understand selected layout editing features of Ansys HFSS 3D Layout IC mode.
4. Perform port setup and simulation of a GDS import.

Course Content

1. 3D Layout GDS Import and Analysis with Ansys HFSS Software
   2. Workshop excercise
   3. Custom model excercise (Based on customer applications)

HRDCorp Claimable Ansys HFSS course

Certificate of completion provided. If based in Malaysia, this course can be reimbursed with the HRDCorp Program through our certified trainers.
