EMHF 202 - Ansys HFSS SBR+ Antenna Placement & Performance Training

Advanced Level Training - 2 days (16 hours)

About Ansys HFSS SBR+ Antenna Placement & Performance Training by CADIT

Training in Shooting and Bouncing Ray (SBR+) simulation in Ansys HFSS for installed antenna analysis on electrically large platforms and antenna-to-antenna coupling. Covers environment modelling, SBR+ setup, materials and boundaries, and result interpretation.

Perfect for RF engineers optimizing antenna placement on large platforms.

Learning Outcomes

By the end of this training, you will be able to:
1. Model antennas installed on platforms with 3D Components and linked near field sources.
2. Set up antenna coupling simulations using far field radiation pattern files in SBR+ solution type simulations and using 3D Components with SBR+ hybrid regions.

Course Content

1. Introduction & 3D Component
   2. Antenna Placement
   3. Antenna Coupling
   4. Car Garage Visual Ray Tracing (VRT)

HRDCorp Claimable Ansys HFSS course

Certificate of completion provided. If based in Malaysia, this course can be reimbursed with the HRDCorp Program through our certified trainers.
