EMHF 102 - Ansys SIwave Introduction Training

Beginner Level Training - 2 days (16 hours)

About Ansys SIwave Introduction Training by CADIT

Practical training in Signal Integrity, Power Integrity, and EMI analysis of high-speed PCBs and packages using Ansys SIwave in Electronics Desktop. Covers project setup, stackup definition, materials, ports, simulation setup, and post-processing on real PCB designs.

Perfect for Engineers and designers of high-speed digital systems.

Learning Outcomes

By the end of this training, you will be able to:
1. Set up Signal Integrity (SI) analyses in Ansys SIwave, including impedance scan, S/Y/Z- parameter extraction, and Time Domain Reflectometry (TDR) simulations.
2. Set up Power Integrity (PI) analyses, such as S/Y/Z, RLGC extraction, and decoupling capacitor optimization.
3. Configure various circuit components including resistors (R), inductors (L), capacitors (C), ports, and terminations.
4. Assign and manage SPICE models and S-parameter models for simulation of complex components.

Course Content

1. Getting Started with Siwave
   - Overview of SIwave capabilities and simulation workflow
   - Importing PCB layouts (ODB++, IPC-2581, BRD)Stack-up and net setup
   2. Signal Integrity (SI) Analysis
   - Impedance scan, S/Y/Z parameter extraction
   - Port setup and TDR wizard
   - Basic crosstalk and transmission line analysis
   3. Power Integrity (PI) Analysis
   - SYZ and RLGC extraction
   - Target impedance and decoupling capacitor analysis
   - IR Drop analysis (single-phase & multiphase
   - VRMs)
   4. Component & Model Configuration
   - Assigning R, L, C, SPICE, and S- parameter models
   5. Optimization & Post-Processing
   - Using PI Advisor for optimization
   - Parametric sweeps and design sensitivity
   - Result visualization and report generation

HRDCorp Claimable Ansys SIwave course

Certificate of completion provided. If based in Malaysia, this course can be reimbursed with the HRDCorp Program through our certified trainers.
